Buchi Evaporator Deluxe Model (PLT-256)

APPLICATIONS OF BUCHI EVAPORATOR DELUXE MODEL
  • Tanco Buchi Evaportor is used for vacuum distillation of solvent at high and low temperature achieved quickly and efficiently by use of a heavy duty motor, which prevents foaming and bumping of the liquid (solvent) into the evaporating flask? is clamped to a glass duct which goes through the drive unit protrudes about 120mm into the condenser.
  • It has a non-sparking motor reduces risk of fire at variable speed for variety of use (90 RPM to 240 RPM). Fitted with speed regulator for minor speed adjustable.
  • It permits continuous feed of solvent into evaporating pear shape flask and also distillation under control atmosphere
SALIENT FEATURES & CONSTRUCTION OF BUCHI EVAPORATOR DELUXE MODEL
  • Supplied with Water Bath Digital and fitted with Digital RPM/Speed Meter
  • Hydraulic lift enables to life the entire glass portion.
  • Rotation by DC motor with RPM range of 20-240rpm
  • Fitted with speed regulator for minor speed adjustable.
  • All glass parts are easily replaceable supplied with 1 Lt. evaporator and receiving flask
  • Condenser is fitted with standard joint at the top and the bottom for receiver flask.
  • User Friendly Ergonomic Design.
  • Works on 220 / 230 volts A.C. supply
  • Low Cost
  • Low Noise
  • Supplied complete with cord & plug
